Starter for Forklifts

Forklift Starters - Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid mounted on it. As soon as current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is situated on the driveshaft and meshes the pinion utilizing the starter ring gear which is seen on the flywheel of the engine.

As soon as the starter motor begins to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid consists of a key operated switch which opens the spring assembly so as to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this method via the pinion to the flywheel ring gear. The pinion remains engaged, like for instance in view of the fact that the driver did not release the key as soon as the engine starts or if the solenoid remains engaged as there is a short. This actually causes the pinion to spin separately of its driveshaft.

The actions mentioned above will stop the engine from driving the starter. This significant step prevents the starter from spinning really fast that it would fly apart. Unless modifications were made, the sprag clutch arrangement will prevent making use of the starter as a generator if it was employed in the hybrid scheme discussed prior. Typically a regular starter motor is meant for intermittent use that will prevent it being used as a generator.

Hence, the electrical parts are intended to work for just about under thirty seconds to be able to avoid overheating. The overheating results from very slow dissipation of heat due to ohmic losses. The electrical parts are designed to save weight and cost. This is the reason the majority of owner's handbooks for vehicles suggest the operator to stop for a minimum of ten seconds after every 10 or 15 seconds of cranking the engine, whenever trying to start an engine that does not turn over instantly.

The overrunning-clutch pinion was launched onto the marked in the early part of the 1960's. Prior to the 1960's, a Bendix drive was used. This particular drive system operates on a helically cut driveshaft that has a starter drive pinion placed on it. When the starter motor begins turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.

The development of Bendix drive was made in the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, made and launched in the 1960s. The Folo-Thru drive has a latching mechanism along with a set of flyweights in the body of the drive unit. This was an improvement since the average Bendix drive used to be able to disengage from the ring as soon as the engine fired, even if it did not stay running.

Once the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement could be prevented before a successful engine start.
